Tc02 Two-Component Coating Machine High Speed Of Glue Production
Equipment Features
● The main motor Imported from Korea and the key parts are made of high strength and high quality stainless steel through heat treatment process,which greatly improves the reliability and durability of the two-component glue coating machine. And ensures the excellent quality of equipment.
● Adopt stainless steel straight line flow mixer,small working resistance,big amount of glue,save glue,no glue leakage and the light weight.
● Component B pressure plate is equipped with two seals,reducing the leakage of component B pressure plate.
● The B component system adopts the first two filters of high pressure output to prevent impurities from entering the high-pressure system and improve the reliability of the machine.
● Compared with the hydraulic model,this machine has high speed of glue production and low failure rate.
You can choose
Detail presentation
Technical Parameter
|
Mixing Ratio |
10:1-14:1 |
Base drum |
55 gallons(200L) |
|
Curing agent barrel |
5 gallons(20L) |
Maximum air consumption |
0.5m³/min |
|
Maximum squeeze pressure |
20MPa |
Overall dimension |
1200*1100*2500mm |
|
Weight |
600kg |
