RONGQI Instruction For the Hot Melt Coating Machine DT-01
Equipment Features
● DJ-01 glue machine is a special mechanical equipment used with hollow glass thermal melt glue. It has small size, light weight, flexible operation and convenient operation. Suitable for construction site use.
● The DT-01 rubber table is a auxiliary platform for the glue machine.
Machine structure
DJ-01 glue machine consists of two parts: glue machine and glue table.
1. Glue Coating Machine
A. Control panel: temperature control instrument, frequency frequency speed adjustment operating panel
B. Plastic warehouse: fill and melt thermal melting glue
C. Glamor pump: melted hot -melt adhesive output
D. Pipe tube: delivery of hot melt glue
E. Gas gun: hot -melt gum control system
2. Glue Coating table
A. Range rack: The operation table rubber gun suspension system with a universal wheel
B. Pneumatic system: manual switching air filter cylinder pressure rod
Technical Parameter
|
Item |
Unit |
Spec |
|
|
Voltage |
Voltage |
V |
220/380 |
|
Frequency |
HZ |
50 |
|
|
Power |
KW |
4.8 |
|
|
Glue warehouse temperature |
℃ |
150 |
|
|
Glue pump temperature |
℃ |
140 |
|
|
Glue pipe temperature |
℃ |
130 |
|
|
Glue head temperature |
℃ |
130 |
|
|
Glue warehouse capacity |
kg |
56 |
|
|
Glue out speed |
g/min |
1000 |
|
|
Glue table pressure |
mpa |
2-4 |
|
|
Glue table weight |
kg |
70 |
|
|
Glue machine weight |
kg |
100 |
|
Detail presentation
Parts Name
(1)Machine frame
(2) Control panel
(3) Temperature control instrument
(4) Inverter
(5) Power indicator light
(6) warehouse cover
(7)glue gun
(8) glue gun power cable
(9)shift
(10)glue pipe
(11) Spring
PARTS NAME
(1) Steel frame
(2) Universal wheel
(3)press rod
(4) Plushu Road
(5) Spring hook
(6) cylinder
(7) Pressing foot
(8) Manual switch
(9) Air filter
