Fully automatic Precision Butyl Extruder Machine
Equipment Features
One click adjustment ▏Stable and efficient ▏Innovative models
1.The flagship model of the fully automatic butyl adhesive coating machine is a star product independently developed and patented model.
2.Innovative one click adhesive head width adjustment method, and the height of the adhesive head can be directly adjusted, which is very convenient to avoid exposure, break through existing thinking, and change traditional concepts.
3.Adopting PLC control, 4-40A one click width adjustment and one click glue addition.
4.20 sets of aluminum strip data can be edited and saved, with a total length of 3.8 meters, making large aluminum strips more practical.
5.The belt is not sticky, the glue head is not leaking, and the glue cylinder is not leaking. It has high work efficiency and stable performance.
Technical Parameter
|
Spacer width |
4～40mm |
Spacer Height |
10mm |
|
Accuracy |
±0.02mm |
Speed |
20~50M/min |
|
Diameter |
180mm |
Length |
500mm |
|
Spacer Temperature |
100～180℃ |
Total powet |
4KW AC220V |
|
Air pressure |
0.6～0.8Mpa |
Dimension |
3800×600×1100mm |
|
Fold Dimension |
2900×600×1100mm |
Main Feature
● Pioneering one click fully automatic width adjustment, capable of editing and saving 20 sets of width data.
● PLC five temperature control, timed automatic startup, timed automatic shutdown.
● 3 minutes for quick gluing, 20 minutes for quick heating, five speeds for one click switching, intelligent one click on/off switch.
● Glue quantity prompt: Glue addition is fully automatic, and one click can add 2 pieces of glue.
● Heating solid-state control, independently developed booster pump.
● Suitable for various colors of aluminum strips.
